Brand: Ray Foster
Model: Model Arch Trimmer
Fast and easy removal of the arch or palate areas of gypsum and stone models is accomplished with Ray Foster.
Model Arch Trimmer and SaberTooth Carbide Burs.
- Large, stainless steel work surface with generous venting for dust removal
- 1-1/2” (38mm) hose connection, connects directly to 1-1/2” vacuum hose, no need for adaptors
- Power output connection for automatic on/off of dust collector
- Safety switch disconnects power when top is removed
- Comes with fast cutting, non-colgging, SaburTooth Carbide Burs, one cylinder and one taper, coarse grit
- Diameter 9" at base
- Height to work surface 8-1/4” (210mm)
- Overall height w/safety shield 13” (330mm)
- Net weight 10-1/2 lb (4-3/4 kg) Shipping weight 12 lb (5-1/2kg)
- 115 volt, 60 Hz standard
◊ Complete trimming system available by ordering with CDC1 Cyclone Dust Collector, order item MR20C
◊ 230 volt, 50/60 Hz Export Model is also Available.
